High Jump Pit
Standard configuration
Width
16'6"
5.03m
Depth
8'
2.44m
Height
24–30"
Overall, top pad included
Starting Price
$5,250
Built by hand in Texas
Warranty
10 Yr
Manufacturing defects
Lead Time
4–6 Wks
Ships all 50 states
| Governing Body | Min. Width | Min. Depth | Dropzone Compliant? |
|---|---|---|---|
| NFHS (High School) | 16' (4.88m) | 8' (2.44m) | ✓ Meets |
| NCAA (Collegiate) | 16' (4.88m) | 8' (2.44m) | ✓ Meets |
| World Athletics | 16' (4.88m) | 8' (2.44m) | ✓ Meets |
| Dropzone Pits Standard | 16'6" (5.03m) | 8' (2.44m) | ✓ NFHS · NCAA · World Athletics |
Governing bodies set the pad footprint as a measurement. Height is not set the same way — the rule asks that the pad be high enough, and of a composition, to provide a safe landing, which is a judgement made about the pit itself. We build high jump at 24–30" and pole vault at 28" or 32" overall, always measured with the 2" top pad on. Check the current rule book for the level you host at, or read how this works in Texas.
Competition Pole Vault Pit
Standard configuration
Width
19'9"
6.0m
Depth
20'5"
6.22m
Height
28" or 32"
Overall, top pad included
Starting Price
$14,500
Built by hand in Texas
Warranty
10 Yr
Manufacturing defects
Lead Time
4–6 Wks
Ships all 50 states
| Governing Body | Min. Width | Min. Depth (behind box) | Dropzone Compliant? |
|---|---|---|---|
| NFHS (High School) | 19'9" (6.0m) | 16'5" (5.0m) | ✓ Meets |
| NCAA (Collegiate) | 19'9" (6.0m) | 19'8" (6.0m) | ✓ Meets |
| World Athletics | 19'9" (6.0m) | 19'8" (6.0m) | ✓ Meets |
| Dropzone Pits Standard | 19'9" (6.0m) | 20'5" (6.22m) | ✓ NFHS · NCAA · World Athletics |
Governing bodies set the pad footprint as a measurement. Height is not set the same way — the rule asks that the pad be high enough, and of a composition, to provide a safe landing, which is a judgement made about the pit itself. We build high jump at 24–30" and pole vault at 28" or 32" overall, always measured with the 2" top pad on. Check the current rule book for the level you host at, or read how this works in Texas.
Construction & Materials
Every Dropzone Pit — same spec, every build
Exterior Casing
UV-resistant vinyl, built to survive outdoors. Resists cracking and UV degradation season after season. Not polyester. Vinyl.
Foam Core
High-density polyurethane foam with cross-section construction that allows air displacement on landing and prevents compression set over time. Not single-block solid foam.
Top Landing Pad
A 2" reversible foam top pad takes the spike and impact abuse so the core foam is protected, and reverses to even out wear. Included on every pit, and counted in the overall height we quote.
Stitching
Double-stitched seams throughout using UV-protected sun guard thread. Every seam is folded before stitching for reinforcement.
Zippers
Marine-grade nylon zippers — the same hardware used on lifejackets — that won't corrode in outdoor conditions. Warranted for the life of the pit.
Modular Velcro Security
Velcro security locks all base sections together as an integrated unit. No gaps between sections during landing.
Built in Texas
Every Dropzone Pit is cut, stitched, and inspected by hand in Texas. Our team builds, quality-checks, and ships each pit. Request a quote →
Response within 24 hours · No sales pressure · Built to order
